Twitter Bikes
⏱ Made to Order: 10-25 Business daysT8 Carbon Road Bike
/
Specification
Key Components
-
Wheel Size: 700C.
-
Frame Size: multiples sizes available
-
Bike Color: Multiples colors available
-
Net Weight: 8.8 kg – 9.3 kg (varies by configuration).
Frame & Structure
-
Frame: T8 (Disc & thru-axle 12×142), high modulus Carbon fiber, Aero-Racing design, full inner-cable routing, Gloss or Matte finish, UV decals.
-
Fork: T8 (Disc & thru-axle 12×100), high modulus Carbon fiber, Road Bike Rigid Fork.
-
Handlebar Set: TW, High modulus Carbon fiber, Aero Integrated Handlebar & Stem, full inner-cable routing.
-
Seat Post: High modulus Carbon fiber, Aero-Racing profile.
-
Clamps: Hidden Screw Fit to Frame.
-
Head Set: Alu alloy CNC with sealed-bearings (52×52mm).
-
Bottom Bracket: DUB Thread T47×29mm, hollow & sealed bearings.
Drivetrain Options
Variant 1 – WheelTop EDS TX 24-Speed Wireless Electronic (Carbon Wave Rim)
-
System: WheelTop EDS TX Wireless Electronic 2×12-speed.
-
Shifters: WheelTop EDS TX Wireless Electronic Shift Lever.
-
Rear Derailleur: WheelTop EDS TX Wireless Electronic Shift - 12 Speeds.
-
Cassette: SUGEK-12 Speed, 11-32T, Colorful.
-
Chain: SUMC-12 Speed, Black Colorful.
-
Brakes: WheelTop Flat Mount Full Hydraulic Disc Brakes, 160/160mm.
Variant 2 – SHIMANO 105 R7120 Mechanical 24-Speed (Carbon Wave Rim)
-
System: SHIMANO 105 R7120, 2×12-speed.
-
Shifters: SHIMANO 105 R7120 - 2×12S.
-
Front Derailleur: SHIMANO 105 R7100 - 2S.
-
Rear Derailleur: SHIMANO 105 R7100 - 12S.
-
Crankset: SENICX-PR1 alu hollow 34-50T.
-
Cassette: SUGEK-12S,11-32T.
-
Brakes: SHIMANO 105 R7070 Hydraulic disc, Centerlock 160/160mm.
Variant 3 – RS (SENSAH) Mechanical 24-Speed (Alloy/Carbon Rim)
-
System: RS (SENSAH) HRD6900, 2×12-speed.
-
Front Derailleur: SHIMANO 105.
-
Rear Derailleur: RS (SENSAH) RD8500-R-GS-12S.
-
Brakes: RS Flat-mount Full Hydraulic Disc, 160/160mm.
Variant 4 – WheelTop EVO TX 28-Speed Wireless Electronic (Carbon)
-
System: WheelTop EVO TX Wireless Electronic 2×14-speed.
-
Shifters: WheelTop EVO TX Wireless Electronic Shift Lever (Carbon).
-
Front Derailleur: WheelTop EVO TX Wireless Electronic – 2 Speeds.
-
Rear Derailleur: WheelTop EVO TX Wireless Electronic – 14 Speeds (Carbon Plate/Large Guide).
-
Crankset: SENICX-XRF Alu DUB Hollow Closed, Gear Ratio: 30-46T.
-
Cassette: CNC Hollow Integrated Colorful – 14 Speeds, 10-36T.
-
Chain: SUMC-14 Speeds, Black Colorful Design.
-
Bottom Bracket: Threaded T47*29mm, Hollow & Sealed Bearings.
-
Brakes: WheelTop Flat Mount Full Hydraulic Disc Brakes, IIIPRO Centerlock Heat-Dissipating Rotor (160/160mm).
Wheelset & Tires
-
Hubs: RS Alu alloy, 4-sealed Bearings, Slotted, F24*R24 holes, Thru-axle F12×100_R12×142.
-
Rims: RS High modulus Carbon Fiber Wave rims (optional) or Alu alloy Double wall, W21×H38mm.
-
Tires: MAXXIS-PURSUER / INNOVA-PRO, Foldable & Reflective, 700*28C (or 27C).
Additional Components
-
Saddle: 3D Printed Saddle / Comfortable & lightweight for racing.
-
Pedals: Alu alloy with Lightweight & Skid-resistant.
-
Cables: JAGWIRE performance cables.
Included Accessories
-
Standard safety reflectors.
-
PC bottle cage + Tools.
-
TW Instruction Manual + Warranty Card (plus Charger for electronic variants).
T8 PRO Features
Why choose this bike
Ultra-lightweight aerodynamic racing frame with 100% internal cable routing for maximum speed.
Title: High-Modulus T800 Aero Carbon Fiber
Title: High-Modulus T800 Aero Carbon Fiber
Aero-Racing Carbon Rigid Fork
T8 specialized carbon fork with thru-axle design for precise handling and vibration damping.
T8 specialized carbon fork with thru-axle design for precise handling and vibration damping.
Wireless Electronic or Shimano Precision
Choose between cutting-edge WheelTop 28-speed wireless electronic shifting or legendary Shimano 105 reliability.
Choose between cutting-edge WheelTop 28-speed wireless electronic shifting or legendary Shimano 105 reliability.
Full Hydraulic Disc Braking System
High-performance hydraulic disc brakes for effortless, all-weather stopping power and total safety.
High-performance hydraulic disc brakes for effortless, all-weather stopping power and total safety.
RS High-Modulus Carbon Wave Rims
Premium 50mm wavy carbon rims designed to provide superior stability and reduce drag in crosswinds.
Premium 50mm wavy carbon rims designed to provide superior stability and reduce drag in crosswinds.
Premium UV Decal Finishes
A wide range of high-gloss or matte finishes with stunning UV-protected holographic and 3K textures.
A wide range of high-gloss or matte finishes with stunning UV-protected holographic and 3K textures.
