⏱ Made to Order: 10-25 Business daysM5 (Boost) - Twitter Carbon Road Bike
/
Key Components
- Frame Size: 29" (27.5") × 15" / 17" / 19"
- Colors: White / Matte Black / Matte Dark Gray / Full Holographic
- Weight: 12.1 kg (M6100 / SRAM) / 12.2 kg (WheelTop)
Frame & Structure
- Frame: M5, high modulus carbon fiber, XC geometry, internal cable routing, thru-axle 12×148 mm Boost
- Fork: TW magnesium-aluminum alloy air suspension, remote lockout, thru-axle 15×110 mm Boost
- Handlebar: Aluminum alloy handlebar (31.8×720 mm) with 80 mm stem
- Seat Post: Aluminum alloy, 31.6×350 mm
- Clamps: Hidden screw, frame-integrated design
- Headset: TW CNC aluminum alloy with sealed bearings (42×52 mm)
- Washer: Carbon 3K, 3×28.6×10 mm
Drivetrain Options
Variant 1 – SHIMANO DEORE M6100 1×12-Speed
- System: SHIMANO DEORE M6100 (1×12-speed)
- Shifters: SHIMANO DEORE M6100
- Front Derailleur: None
- Rear Derailleur: SHIMANO DEORE M6100 12-speed
- Crankset: SENICX FM3 aluminum alloy hollow 36T
- Cassette: SUNSHINE 12-speed, 11–50T
- Chain: SUMC 12-speed
- Bottom Bracket: BB92×41×24 mm, press-fit
Variant 2 – WheelTop EDS OX 1×13-Speed (Wireless)
- System: WheelTop EDS OX wireless hydraulic (1×13-speed)
- Shifters: WheelTop EDS OX wireless 13-speed
- Front Derailleur: None
- Rear Derailleur: WheelTop EDS OX wireless 13-speed
- Crankset: SENICX FM3 aluminum alloy hollow 36T
- Cassette: SUNSHINE 13-speed, 11–50T
- Chain: SUMC 13-speed
- Bottom Bracket: BB92×41×24 mm, press-fit
Variant 3 – SRAM SX Eagle 1×12-Speed
- System: SRAM SX Eagle (1×12-speed)
- Shifters: SRAM SX Eagle 12-speed
- Front Derailleur: None
- Rear Derailleur: SRAM SX Eagle 12-speed
- Crankset: SRAM SX Eagle DUB 34T
- Cassette: SRAM PG1210 Eagle 12-speed, 11–50T
- Chain: SRAM SX Eagle 12-speed
- Bottom Bracket: BB92×41×29 mm, press-fit
Wheelset & Tires
- Hubs: RS aluminum alloy & carbon fiber, 4 sealed bearings, disc-compatible, 32 holes, Boost F15×110 / R12×148
- Rims: RS aluminum alloy, double wall with rivets, W25×H21 mm
- Spokes: SHUNJIU circular 14G
- Tires: INNOVA PRO 29" (27.5") × 2.1", black
Braking System
- Brakes: SHIMANO MT200 hydraulic disc, 160 mm front / 160 mm rear
Additional Components
- Grips: PU leather locking grips, 22.2×120 mm
- Saddle: Lightweight and comfortable MTB saddle
- Pedals: Lightweight & skid-resistant
- Cables: JAGWIRE internal & external routing
Included Accessories
- Reflectors: Handlebar, seat post, front wheel, rear wheel
- Extras: Bottle cage + tools
- Documentation: Manual + warranty card
M5 (Boost) Features
Why choose this bike
Carbon Fiber Boost Frame
High modulus carbon frame with 12×148 mm Boost for stiffness and acceleration.
High modulus carbon frame with 12×148 mm Boost for stiffness and acceleration.
Air Suspension Fork
TW magnesium–aluminum air fork with remote lockout enhances control and comfort.
TW magnesium–aluminum air fork with remote lockout enhances control and comfort.
Multi-System Options
Available with SHIMANO DEORE, SRAM Eagle, or WheelTop OX wireless drivetrains.
Available with SHIMANO DEORE, SRAM Eagle, or WheelTop OX wireless drivetrains.
Hydraulic Disc Brakes
SHIMANO MT200 provides consistent braking across technical XC trails.
SHIMANO MT200 provides consistent braking across technical XC trails.
RS Alloy Boost Wheelset
Durable double-wall rims with carbon hubs for smooth, reliable performance.
Durable double-wall rims with carbon hubs for smooth, reliable performance.
Sleek Carbon Finish
Offered in White, Matte Black, Matte Dark Gray, and Full Holographic for a bold modern
look.Offered in White, Matte Black, Matte Dark Gray, and Full Holographic for a bold modern look.
Advanced Drivetrain Systems
Wireless or mechanical precision
Choose between SHIMANO, SRAM, or WheelTop systems for smooth shifting across all terrains.
Full Carbon Boost Frame
Rigid and lightweight
The M5’s carbon Boost frame provides stiffness and precise power transfer for advanced XC control.
