Gravel V3 PRO (Premium Edition) – Full Carbon Gravel Bike

Key Components

• Wheel Size: 700C

• Frame Size: 45cm / 48cm / 50cm / 52cm / 54cm

• Bike Color: Multiple colors available

• Net Weight: 9.6 kg (varies slightly by configuration)

Frame & Structure

• Frame: Gravel V3 (Disc & thru-axle 12×142), high modulus Carbon fiber, XC geometry, full inner-cable routing.

• Fork: Gravel V3 (Disc & thru-axle 12×100), high modulus Carbon fiber, XC, 700C.

• Handlebar Set: TW 3K Carbon fiber, Integrated Handlebar & Stem (380×80 / 400×90 / 420×100mm), full inner-cable routing, 30° outward expansion.

• Seat Post: High modulus Carbon fiber, Aero-Racing design (Optional: 3K bright black or UD black finish).

• Clamps: Hidden Screw Fit to Frame.

• Head Set: CNC Aluminum alloy with sealed bearings (52×52mm).

• Bottom Bracket: Threaded T47 (varies by groupset).

Drivetrain Options

Variant 1 – SHIMANO 105 R7120 Mechanical 24-Speed (2×12)

• System: SHIMANO 105 R7120 Hydraulic 2×12-Speed.

• Shifters: SHIMANO 105 R7120 Dual Control Levers (Hydraulic, Mechanical).

• Front Derailleur: SHIMANO 105 R7100 – 2-Speed.

• Rear Derailleur: SHIMANO 105 R7100 – 12-Speed.

• Crankset: SHIMANO 105 R7100 Hollowtech II, 34-50T.

• Cassette: SHIMANO 105 R7100-12S, 11-34T.

• Chain: SHIMANO HG6100-12S.

• Bottom Bracket: Threaded T47×24mm.

• Brakes: SHIMANO 105 R7070 Hydraulic Disc, Center Lock 160/160mm.

Variant 2 – SHIMANO 105 R7170 Di2 Electronic 24-Speed (2×12)

• System: SHIMANO 105 R7170 Di2 Wireless Electronic 2×12-Speed.

• Shifters: SHIMANO 105 R7170 Dual Control Levers (Wireless Electronic & Hydraulic).

• Front Derailleur: SHIMANO 105 R7150 Di2 – 2-Speed.

• Rear Derailleur: SHIMANO 105 R7150 Di2 – 12-Speed.

• Crankset: SHIMANO 105 R7100 Hollowtech II, 34-50T.

• Cassette: SHIMANO 105 R7101-12S, 11-34T.

• Chain: SHIMANO HG-M7100-12S.

• Bottom Bracket: Threaded T47×24mm.

• Brakes: SHIMANO 105 R7170 Hydraulic Disc, SHIMANO RT70 Center Lock 160/160mm.

Variant 3 – SRAM Rival AXS Wireless 12-Speed (1×12)

• System: SRAM Rival eTap AXS Wireless Electronic 1×12-Speed.

• Shifters: SRAM Rival eTap AXS Wireless Hydraulic.

• Front Derailleur: None (1× configuration).

• Rear Derailleur: SRAM Rival XPLR eTap AXS Wireless 12-Speed.

• Crankset: SRAM Rival DUB WIDE, 42T.

• Cassette: SRAM XG-1251 XPLR 12-Speed, 10-44T.

• Chain: SRAM Rival 12-Speed.

• Bottom Bracket: Threaded T47×29mm (DUB).

• Brakes: SRAM Rival Hydraulic Disc, SHIMANO RT70 Center Lock 160/160mm.

Wheelset & Tires

• Hubs: RS, Aluminum alloy & Carbon fiber body, 4-sealed bearings, Center Lock Disc, Thru-axle F12×100 / R12×142, F24×R24 holes.

• Rims: RS AL7005 Alloy “Wave” Profile, W19×H38mm×700C.

• Spokes: Circular 14G.

• Tires: MAXXIS OVERDRIVE EXCEL, Wire Bead, 700×40C, Black.

Additional Components

• Belt: PU with comfortable & skid-resistant surface.

• Saddle: 3D Printed Saddle (Standard).

• Pedals: Lightweight & Skid-resistant Alloy.

• Cables: JAGWIRE Performance Cables.

Included Accessories

• Standard safety reflectors (Handlebar, Seat Post, Front Wheel, Rear Wheel).

• PC Bottle Cage + Tools.

• User Manual + Warranty Card.
