Key Components

• Handlebar Set: RS aluminum alloy, matte; Handlebar 31.8×720mm, Stem 60mm, Clamp 34.9mm

• Seatpost:

  • Variant A/B: RS aluminum alloy, matte, 31.6×350mm

  • Variant C: KS adjustable hydraulic dropper, remote, 31.6×395×125mm

• Headset: Aluminum alloy CNC, sealed bearings, 52×52mm

• Grips: 22.2×120mm PU leather with locking ring

• Saddle: RS MTB, thickened comfort design

• Pedals: RS aluminum alloy CNC with bearings

Frame & Structure

• Frame: CYCTRAC EM6, AL7005 aluminum alloy, flat welds, internal routing, 12×148 Boost, 140mm rear travel, DNM rear shock 200×55mm

• Frame Size: 29(27.5)×16" / 18"

• Colors: Matte Black / Dark Green / Dark Blue / Dark Red

• Net Weight:

  • Variant A: 24.5 kg

  • Variant B: 24.9 kg

  • Variant C: 25.7 kg

Fork Options

• RS MgAl alloy, air, manual lock, 150mm travel, thru-axle 15×110

• ROCKSHOX RECON, air, manual, 150mm, thru-axle 15×110 (Variant C)

Variant Options (Clean Presentation)

Variant A — M510 Motor + Shimano M6100 (12-Speed)

• Motor: Bafang M510, 36V/48V 250W

• Max Torque: 95 N·m (Peak 130 N·m)

• Drivetrain: Shimano DEORE M6100 12-speed

• Cassette: SUNSHINE 11–50T

• Chain: SUMC 12-speed

• Battery: Samsung 720Wh, 36V20A (48V15A)

• Range: 120–140 km

• Seatpost: RS alloy

• Fork: RS air, 150mm

Variant B — M560 Motor + Shimano M6100 (12-Speed)

• Motor: Bafang M560, 48V 500W

• Max Torque: 130 N·m (Peak 150 N·m)

• Drivetrain: Shimano DEORE M6100 12-speed

• Cassette: SUNSHINE 11–50T

• Chain: SUMC 12-speed

• Battery: Samsung 720Wh, 48V15A

• Range: 110–130 km

• Seatpost: RS alloy

• Fork: RS air, 150mm

Variant C — M560 Motor + Wheeltop Wireless (12-Speed)

• Motor: Bafang M560, 48V 500W

• Max Torque: 130 N·m (Peak 150 N·m)

• Drivetrain: Wheeltop EDS OX-12S wireless

• Cassette: SUNSHINE 11–50T

• Chain: SUMC 12-speed

• Battery: Samsung 720Wh, 48V15A

• Range: 110–130 km

• Seatpost: KS hydraulic dropper, remote

• Fork: ROCKSHOX RECON, 150mm

Motor System & Electronics

• Speed Limit: 25 km/h (max 45 km/h)

• Pedal Sensor: Torque + speed (cadence)

• Charging Time: 6–7 hours

• Charger: 3A, DC2.1

• Display: Bafang C245 LCD

• Waterproof Rating: IPX6

• Max Load: 130 kg

Wheelset & Tires

• Hubs: RS aluminum alloy, 4-sealed bearings, disc, 32H; thru-axle F15×110 / R12×148 Boost

• Rims: RS aluminum alloy, double-wall, riveted, W25×H21mm

• Spokes: SHUNJIU 14G circular

• Tires: MAXXIS 29/27.5×2.25"

Braking System

• RS-LD400 aluminum alloy CNC, 4-piston hydraulic brakes, 203/203mm rotors
