R10-Disc – Carbon Road Bike with SHIMANO 105 Di2 (R7170) 2×12-Speed & Hydraulic Disc Brakes
- Frame: High-modulus carbon (T800&T1000), aero design, internal cable routing, 12×142/12×100 thru-axles
- Drivetrain: SHIMANO 105 Di2 – 2×12-speed (R7170 shifters, R7150 derailleurs)
- Brakes: Hydraulic disc 160/160
- Wheelset: Carbon spoke & carbon rim (T800&T1100), RS-H280 hubs with 54T ratchet
- Design: Integrated carbon cockpit, race-focused geometry
- Use: Ideal for fast training, racing, and endurance road riding
- Colors: White / MatteBlack / MatteInkBlue
R10 PRO (Race ED) is a high-performance carbon road bike focused on aerodynamic efficiency, precision handling, and modern disc-brake control. The R10-DISC frame uses high-modulus Carbon fiber T800 & T1000 with fully internal cable routing and 12×142/12×100 thru-axles. It comes equipped with the latest SHIMANO 105 Di2 (R7170) 2×12-speed electronic groupset and a premium carbon spoke & carbon rim wheelset for ultra-fast rolling.
Technical Specifications
Key Components
-
Wheel Size: 700C
-
Frame Height: 43cm / 46cm / 48cm / 51cm / 54cm
-
Bike Color: White / MatteBlack / MatteInkBlue
-
Net Weight: 7.8 kg
Frame & Structure
-
Frame: R10 (Disc & thru-axle 12×142), high modulus carbon fiber T800 & T1000, aero design, full internal cable routing
-
Fork: R10 (Disc & thru-axle 12×100), high modulus carbon fiber T800, 700C
-
Seat Post: High modulus carbon fiber, Aero-Racing profile
-
Clamps: Hidden screw fit to frame
-
Head Sets: Aluminum alloy CNC with sealed bearings, 52×52 mm
-
Washer: Dedicated for inner-cables
Handlebar & Cockpit
-
Handlebar Set: High modulus carbon fiber, integrated handlebar & stem (400×90 mm), full internal cables
Drivetrain
|
SHIMANO 105 Di2 — R7170 (2×12-Speed) |
| Shift Levers |
SHIMANO 105 / R7170 — 2×12S, Di2 |
| Front Derailleur |
SHIMANO 105 / R7150 — 2S, Di2 |
| Rear Derailleur |
SHIMANO 105 / R7150 — 12S, Di2 |
| Crankset |
SHIMANO 105 / R7100 — 34–50T |
| Cassette |
SHIMANO 105 / R7100 — 12S, 11–34T |
| Chain |
SHIMANO M7100 — 12S |
| Bottom Bracket |
Threaded T47×24 mm, hollow & sealed bearings |
Braking System
-
Brake: SHIMANO 105 / R7170 hydraulic disc, 160/160
Wheelset & Tires
-
Hubs: RS-H280, aluminum alloy & ultralight, 54T ratchet, 4-sealed bearings, HG, Centerlock, thru-axle F12×100 / R12×142
-
Rim: RS, high modulus carbon fiber T800 & T1100, flat, W28×H58 mm, 700C
-
Spokes: High modulus carbon fiber, 5.2
-
Tires: MAXXIS – PURSUER, foldable & lightweight, 700×28C, black
-
Belt: PU with comfortable & skid-resistant surface
-
Saddle: RS carbon fiber, comfortable & ultralight for racing
-
Pedals: Aluminum alloy with sealed bearings
-
Cables: JAGWIRE
Upgrade Painted carbon wheels available in white or holographic color (adds style only) +$40.
What’s Included
- Standard safety reflectors (handlebar, seat post, front wheel, rear wheel)
- PC bottle cage + Tools
- Manual + Warranty card
How to Pay for Upgrades: Add the bike to your cart, list desired upgrades in the notes field, and complete checkout. You’ll receive a separate invoice by email once your purchase is confirmed.
Decal & Finish Disclaimer: Actual decals, graphics, and finishes may differ from the photos shown due to batch variations, lighting, and screen display settings.
